MIL-PRF-15733/41H
Insertion-loss: Not applicable.
Vibration, high frequency: In accordance with MIL-PRF-15733 and method 204, MIL-STD-202; test condition D for
-0001 through -0005 and test condition B for -0006. The following exception shall apply:
Electrical current load shall not be applied to filters during the vibration test.
Life: In accordance with MIL-PRF-15733 and method 108, MIL-STD-202; test condition B.
Test temperature +125°C.
VERIFICATION
Qualification inspection: In accordance with MIL-PRF-15733 except that the transient voltage test shall be
included as an additional test Group (see table II).
TABLE II. Qualification inspection. 1/
Inspection
Number of samples
Number of
to be inspected
defectives allowed
Group VI
0
4
Transient voltage
1/ This table is in addition to table III of MIL-PRF-15733.
Conformance inspection: In accordance with MIL-PRF-15733 except that prior to Group A inspection, 100 percent
of each lot of filters shall be subjected to voltage conditioning as specified herein and the transient voltage test
shall be included as an additional subgroup in Group C inspection (see table III).
TABLE III. Group C inspection. 1/
Inspection
Number of samples
Number of
to be inspected
defectives allowed
Subgroup VI
0
4
Transient voltage
1/ This table is in addition to table VI of MIL-PRF-15733.
Part or identifying number (PIN): M15733/41- (dash number from table I).
NOTES:
Referenced documents: In addition to MIL-PRF-15733, this specification sheet references the following
documents:
MIL-STD-202
MIL-STD-704
Changes from previous issue. Marginal notations are not used in this revision to identify changes with respect to
the previous issue due to the extensiveness of the changes.
7
