MIL-PRF-15733/41H
Filter hardware dimensions.
Mounting hardware
Dash
Hex nut
Lockwasher
no.
J
K
L
M
N
P
0001
.615
.095
.4375-20
.744
.033 REF.
.448
.635
.156
UNF-2B
.789
.464
0002
1.052
.141
.750-20
1.047
.017
.757
1.072
.171
UNF-2B
1.077
.027
.760
0003
1.052
.141
.750-20
1.047
.017
.757
1.072
.171
UNF-2B
1.077
.027
.760
0004
.865
.146
.625-24
.867
.017
.640
0006
.885
.166
UNF-2B
.883
.027
.659
0005
.615
.095
.4375-20
.744
.033 REF.
.448
.635
.156
UNF-2B
.789
.464
inches
mm
inches
mm
inches
mm
.017
0.43
.448
11.38
.760
19.30
.027
0.69
.464
11.79
.789
20.04
.033
0.84
.615
15.62
.865
21.97
.095
2.41
.625
15.88
.867
22.02
.141
3.58
.635
16.13
.883
22.43
.146
3.71
.640
16.26
.885
22.48
.156
3.96
.659
16.74
1.047
26.59
.166
4.22
.744
18.90
1.052
26.72
.171
4.34
.750
19.05
1.072
27.23
.4375
10.11
.757
19.23
1.077
27.36
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Circuit diagram is for information only.
4. Mounting hardware (internal-tooth lockwasher and hex nut) shall be supplied with filter.
5. Terminal shape and angular orientation optional.
FIGURE 1. Case dimensions and circuit diagrams - Continued.
3
