MIL-PRF-15733/44F
Terminal strength: In accordance with MIL-PRF-15733 and Method 211, MIL-STD-202; test condition A.
Applied force: 5 pounds.
Salt atmosphere (corrosion): In accordance with MIL-PRF-15733 and Method 101, MIL-STD-202; test condition
A, except that the salt solution concentration shall be 20 percent.
TABLE I. Electrical characteristics.
Minimum insertion loss (dB) in accordance with MIL-STD-220, at +25°C.
Voltage drop
Dash
maximum
number
Volts
Volts
4
10
100
150
500
1
5
1 GHz to
10 Ghz
dc
ac rms
MHz
MHz
MHz
MHz
MHz
GHz
GHz
18 GHz
to 18 GHz
0001
0.30
0.20
---
10
30
---
55
---
---
65
---
0002
0.10
0.07
3
5
20
---
40
---
---
50
---
0003
0.05
0.03
---
---
---
3
---
16
35
---
42
Minimum insertion loss (dB) in accordance with MIL-STD-220, at -55°C and +125°C
Dash
number
4
10
100
150
500
1
5
1 GHz to
10 GHz
MHz
MHz
MHz
MHz
MHz
GHz
GHz
18 GHz
to 18 GHz
0001
---
8
28
---
53
---
---
65
---
0002
---
3
18
---
38
---
---
50
---
0003
---
---
---
---
---
16
35
---
42
Shock (specified pulse): In accordance with MIL-PRF-15733 and Method 213, MIL-STD-202; test condition C.
Vibration, high frequency: In accordance with MIL-PRF-15733 and Method 204, MIL-STD-202; test condition D
(20 g).
Part or Identifying Number (PIN): M15733/44- (dash number from table I).
Marking: Each filter shall be marked with the PIN, as shown on figure 2. In addition, full marking
in accordance with method I requirements of MIL-STD-1285 shall be marked on each unit package.
FIGURE 2. Hex flats - expanded view.
Application note: These nonhermetically sealed filters may be susceptible to moisture intrusion when subjected to
repeated thermal cycling. If these items are to be utilized in applications enduring harsh environments, the user
should consider placing them within hermetic enclosures.
4
