MIL-PRF-15733/43E
Filter dimensions.
Dimension
Dash
number
A
B
C
D
E
Min
Max
Min
Max
Min
Max
Min
Max
Min
Max
0001
.208
.228
.271
.291
.781
.843
.177
.197
.349
.369
(5.28)
(5.79)
(6.88)
(7.39)
(19.84) (21.41)
(4.50)
(5.00)
(8.86)
(9.37)
0002
.206
.226
.256
.276
.859
.921
.083
.103
.281
.343
(5.23)
(5.74)
(6.50)
(7.01)
(21.82) (23.39)
(2.11)
(2.62)
(7.14)
(8.71)
0003
.203
.233
.266
.296
.750
.874
.172
.202
.328
.390
(5.16)
(5.92)
(6.76)
(7.52)
(19.05) (22.20)
(4.37)
(5.13)
(8.33)
(9.91)
Dash
Dimension
number
G
H
J
K
L
Min
Max
Min
Max
Min
Max
Thread
Min
Max
0001
.240
.260
.050
.070
.010
.030
.216-28
.027
.037
(6.10)
(6.60)
(1.27)
(1.78)
(0.25)
(0.76)
UNF-2A
(0.69)
(0.94)
0002
.177
.197
.050
.070
.010
.030
.164-32
.027
.037
(4.50)
(5.00)
(1.27)
(1.78)
(0.25)
(0.76)
UNC-2A
(0.69)
(0.94)
0003
.235
.265
.050
.070
.010
.030
.216-32
.035
.045
(5.97)
(6.73)
(1.27)
(1.78)
(0.25)
(0.76)
UNEF-2A
(0.89)
(1.14)
Hardware dimensions
Hex nut
Lockwasher
Dash
number
A
B
C
D
E
F
Min
Max
Min
Max
Thread
Min
Max
Min
Max
Min
Max
0001
.240
.260
.070
.080
.216-28
.351
.369
.045
.051
.219
.229
(6.10)
(6.60)
(1.78)
(2.03)
UNF-2B
(8.92)
(9.37)
(1.14)
(1.30)
(5.56)
(5.82)
0002
.240
.260
.073
.078
.164-32
.263
.273
.034
.038
.168
.176
(6.10)
(6.60)
(1.85)
(1.98)
UNC-2B
(6.68)
(6.93)
(0.86)
(0.97)
(4.27)
(4.47)
0003
.302
.322
.070
.080
.216-32
.371
.381
.020
.024
N/A
N/A
(7.67)
(8.18)
(1.78)
(2.03)
UNEF-2B
(9.42)
(9.68)
(0.51)
(0.61)
FIGURE 1. Case and circuit diagram - Continued.
2
