MIL-F-15733/1J
TABLE I. Electrical characteristics.
Dash
Circuit
Rated
Rated
Minimum insertion loss (dB) in accordance with
MIL-STD-220 at +25°C 1/
number
diagram
voltage
current
(V dc)
(A)
.15
.30
.60
1
10
100
1,000
MHz
MHz
MHz
MHz
MHz
MHz
MHz
š
0001
100
1
50
60
60
60
60
60
60
š
0002
100
5
40
50
60
60
60
60
60
š
0003
100
5
50
60
60
60
60
60
60
š
0004
100
10
40
50
60
60
60
60
60
š
0005
100
10
50
60
60
60
60
60
60
š
0006
100
20
50
60
60
60
60
60
60
š
0007
100
30
50
60
60
60
60
60
60
1/ Full load insertion loss measurements shall be performed at frequencies between 150 kHz
to 20 MHz inclusive; all other measurements shall be performed at no-load.
Dielectric withstanding voltage: In accordance with MIL-PRF-15733 except the duration of application of voltage
shall be 1 to 5 seconds.
Insulation resistance: In accordance with MIL-PRF-15733. Insulation resistance measured between both
terminals connected together and the case shall be at least:
Dash numbers
0001, 0002, and 0004 - 1,000 megohms.
0003, 0005, 0006, and 0007 - 500 megohms.
Voltage drop: .5 volt, maximum.
Terminal strength: In accordance with MIL-PRF-15733 and the following:
Style 2 - method 211, MIL-STD-202; test condition E.
Style 1 - method 211, MIL-STD-202; test conditions A (applied force: 5 pounds) and B (5 bends).
Salt atmosphere (corrosion): In accordance with MIL-PRF-15733 and method 101, MIL-STD-202; test condition A.
Shock (specified pulse): In accordance with MIL-PRF-15733 and method 213, MIL-STD-202; test condition I.
Mounting: Filters shall be rigidly mounted by the body.
Insertion loss shall be measured and shall meet initial requirements.
Vibration, high frequency: In accordance with MIL-PRF-15733 and method 204, MIL-STD-202; test condition D
(20g).
Part or Identifying Number (PIN): M15733/01- (dash number from figure 1 and table I).
The Qualified Products List (QPL) associated with this inactive for new design specification will be maintained until
acquisition of the products is no longer required where upon the specification and QPL will be canceled.
