MIL-F-15733/1J
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Case: Metal.
*
Case and mounting hardware finish: In accordance with MIL-PRF-15733. Pure tin finish is prohibited as
specified in MIL-PRF-15733.
Terminals:
Style 1 - Solderable.
Style 2 - Threaded stud.
*
Recommended terminal torque:
Thread
Torque (in-lb)
.190-32
16 to 18
UNF-2A
*
Recommended mounting torque:
Thread
Torque (in-lb)
Thread
Torque (in-lb)
.312-24
25 to 30
.625-24
100 to 115
UNF-2A
UNEF-2A
.437-20
60 to 70
.750-20
120 to 140
UNF-2A
UNEF-2A
.500-28
85 to 95
UNEF-2A
Weight: See figure I.
Operating temperature range: -55°C to +85°C.
Rated voltage: See table I.
Rated current: See table I.
Insertion loss: In accordance with MIL-PRF-15733 and the following:
(at +25°C): See table I.
(at -55°C and +85°C): Insertion loss shall be as specified in table I except that a degradation of 2 dB from
the value specified in table I shall be allowed up to 10 MHz.
Seal: In accordance with MIL-PRF-15733.
Temperature rise: In accordance with MIL-PRF-15733 and the following:
25°C maximum for parts rated up to and including 10 amperes.
35°C maximum for parts rated above 10 amperes.
3
