MIL-F-15733/1J
Dimensions.
Dash
A
B
C
D
E
F
G
No.
Min
Max
Min
Max
Min
Max
Min
Max
Min
Max
Min
Max
0001
2.032
2.156
.688
.812
.172
.312
.265
.286
.125
.250
.245
.255
.09 x .187
(51.61)
(54.76)
(17.48)
(20.62)
(4.37)
(7.92)
(6.73)
(7.26)
(3.18)
(6.35)
(6.22)
(6.48)
0002
2.313
2.437
.938
1.062
.141
.312
.359
.380
.125
.312
.435
.445
.06 x .125 or
(58.75)
(61.90)
(23.83)
(26.97)
(3.58)
(7.92)
(9.12)
(9.65)
(3.18)
(7.92)
(11.05)
(11.30)
.09 x .187
0003
2.688
2.812
.938
1.062
.125
.250
.359
.380
.125
.250
.435
.445
.06 x .125 or
(68.28)
(71.42)
(23.83)
(26.97)
(3.18)
(6.35)
(9.12)
(9.65)
(3.18)
(6.35)
(11.05)
(11.30)
.09 x .187
0004
2.688
2.812
1.063
1.187
.187
.312
.370
.380
.187
.312
.365
.375
.09 x .187
(68.28)
(71.42)
(27.00)
(30.15)
(4.75)
(7.92)
(9.40)
(9.65)
(4.75)
(7.92)
(9.27)
(9.52)
0005
2.438
2.562
1.188
1.312
.125
.250
.370
.380
.125
.250
.525
.535
.093 Dia.
(61.93)
(65.07)
(30.18)
(33.32)
(3.18)
(6.35)
(9.40)
(9.65)
(3.18)
(6.35)
(13.34)
(13.59)
0006
2.938
3.062
1.313
1.437
.308
.410
.370
.380
.308
.410
.525
.535
N/A
(74.63)
(77.77)
(33.35)
(36.50)
(7.82)
(10.41)
(9.40)
(9.65)
(7.82)
(10.41)
(13.34)
(13.59)
0007
3.188
3.312
1.438
1.562
.308
.410
.370
.380
.308
.410
.650
.660
N/A
(80.98)
(84.12)
(36.53)
(39.67)
(7.82)
(10.41)
(9.40)
(9.65)
(7.82)
(10.41)
(16.51)
(16.76)
Dash
H
J
K
L
M
N
Mounting Terminal
Terminal
No.
thread
thread
style
Min
Max
Min
Max
Min
Max
Min Max
Max
Min
Max
0001
.017
.027
.12
.13
.427
.447
N/A
3.00
N/A
.312-24
N/A
1
(.43)
(.69)
(3.0)
(3.3)
(10.85)
(11.35)
(76.2)
UNF-2A
0002
.017
.027
.12
.13
.615
.698
N/A
3.63
N/A
.500-28
N/A
1
(.43)
(.69)
(3.0)
(3.3)
(15.62)
(17.73)
(92.2)
UNEF-2A
0003
.017
.027
.12
.13
.615
.698
N/A
3.78
N/A
.500-28
N/A
1
(.43)
(.69)
(3.0)
(3.3)
(15.62)
(17.73)
(96.0)
UNEF-2A
0004
.03
.04
.12
.13
.615
.635
N/A
3.82
N/A
.437-20
N/A
1
(.8)
(1.0)
(3.0)
(3.3)
(15.62)
(16.13)
(97.0)
UNF-2A
0005
.017
.027
.151
.161
.865
.885
N/A
3.44
N/A
.625-24
N/A
1
(.43)
(.69)
(3.84)
(4.09)
(21.97)
(22.48)
(87.4)
UNEF-2A
0006
.017
.027
.151
.161
.865
.885
.12 .13
4.85
.37
.38
.625-24
.190-32
2
(.43)
(.69)
(3.84)
(4.09)
(21.97)
(22.48) (3.0) (3.3)
(123.2)
(9.4) (9.7) UNEF-2A UNF-2A
0007
.017
.027
.151
.161
1.052
1.072
.12 .13
5.03
.37
.38
.750-20
.190-32
2
(.43)
(.69)
(3.84)
(4.09)
(26.72)
(27.23) (3.0) (3.3)
(127.8)
(9.4) (9.7) UNEF-2A UNF-2A
Dash
Max weight
Inches
mm
Inches
mm
No.
lbs.
.06
1.5
.125
3.18
0001
.12
.09
2.3
.187
4.75
0002
.24
.093
2.36
0003
.26
0004
.33
0005
.39
0006
.58
0007
.78
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are in parenthesis.
3. Metric equivalents are given for general information only.
4. Mounting hardware shall be supplied with the filter.
5. Circuit diagram is for information only.
FIGURE 1. Case dimensions and circuit diagrams - Continued.
2
