A-A-55506 Filter, Radio Frequency InterferenceThis CID covers the general requirements for radio frequency interference \(RFI\) suppression power line filters. These filters consist of capacitors and inductors used in combination with each other and are provided with resistors as a safety feature. This series of RFI filters incorporate the special international Electrotechnical Commission \(IEC\) power line connector. Filters covered by this CID are intended for commercial/industrial applications and should not be used in military systems needing stringent environmental and electrical requirements.

Pages 1 - 2 - 3 - 4 - 5


A-A-55506A
Inches
mm
0.13
.005
1.8
.07
3.98
.157
5.96
.235
6.35
.250
23.1
.09
32.89
1.295
40.01
1.575
A
B
C
D
E
(max)
(max)
(max)
(max)
PIN
.015/ .38
AA55506-
Inch
mm
Inch
mm
Inch
mm
Inch
mm
Inch
mm
01, 02
3.21
81.5
2.25
57.2
1.28
32.5
1.575
40.01
.63
16.0
03, 04
3.21
81.5
2.25
57.2
1.28
32.5
1.575
40.01
.63
16.0
05, 06
3.21
81.5
2.25
57.2
1.28
32.5
1.575
40.01
.63
16.0
07, 08
3.21
81.5
2.25
57.2
1.28
32.5
1.575
40.01
.63
16.0
09, 10
3.71
94.2
2.25
57.2
1.28
32.5
1.575
40.01
.63
16.0
11, 12
3.71
94.2
2.25
57.2
1.28
32.5
1.575
40.01
.63
16.0
NOTES:
1.
Dimensions are in inches.
2.
Metric equivalents are given for general information only.
3.
Fastons: (Three) .250 inch (6.35 mm).
.
Holes: .07 inch (1.8 mm) diameter.
4.
Thread sizes: No. 6-32 x .250 (M-3 x .5) (2).
5.
Metric equivalents are in parentheses.
FIGURE 2. Case configuration and dimensions.
3
