[INCH-POUND]
A-A-55506A
September 17, 2001
SUPERSEDING
A-A-55506B
December 25, 1993
COMMERCIAL ITEM DESCRIPTION
FILTER, RADIO FREQUENCY INTERFERENCE
The General Services Administration has authorized the use
of this commercial item description (CID) for all federal agencies.
1. SCOPE. This CID covers the general requirements for radio frequency interference (RFI) suppression power line
filters. These filters consist of capacitors and inductors used in combination with each other and are provided with
resistors as a safety feature. This series of RFI filters incorporate the special international Electrotechnical
Commission (IEC) power line connector. Filters covered by this CID are intended for commercial/industrial
applications and should not be used in military systems needing stringent environmental and electrical requirements.
2. CLASSIFICATION. This CID uses a classification system which is included in the Part Identification Number
(PIN) as shown in the following example (see 7.1).
AA55506
-
01
CID number
Dash number
3. SALIENT CHARACTERISTICS.
3.1 Interface and physical dimensions. Filters supplied to this CID shall be as specified herein (see figures 1 and 2).
3.2. Voltage rating. The voltage rating shall be 120 V ac at 60 Hz; 250 V ac at 50 Hz.
3.3 Operating frequency. The operating frequency shall be 50/60 Hz.
3.4 Current rating. The current rating shall be as specified in table I.
3.5 Operating ambient temperature range. The operating ambient temperature range shall be -10 C to +40 C at
rated current.
3.6 Maximum leakage current, line-to-ground. The maximum leakage current for configuration 1, line-to-ground,
shall be 0.25 mA at 120 V ac, 60 Hz; .50 mA at 250 V ac, 50 Hz. The maximum leakage current for configuration 2,
line-to-ground, shall be 0.5 mA at 120 V ac, 60 Hz; 1.0 mA at 250 V ac, 50 Hz.
3.7 Hipot rating (1 minute). The hipot rating shall be 2,250 V dc line-to-ground; 1,450 V dc line-to-line.
3.8 Insertion loss. Insertion loss is given for line-to-ground in a 50-ohm circuit. Values shall be as specified in table I.
3.9 Electrical schematics. The electrical schematics shall be as specified on figure 1.
3.10 Marking. Filters supplied to this CID shall be marked with the manufacturer's (MFR's) standard commercial
PIN.
