A-A-55506A
TABLE I. Current rating and insertion loss.
Current
Leakage
Minimum insertion loss (dB)
Minimum insertion loss (dB)
rating
current
Line-to-ground in 50-ohm circuit
Line-to-line 50-ohm circuit
PIN
config.
AA55506-
Frequency (MHz)
Frequency (MHz)
.15 .5
1
5
10
30
.15 .5
1
5
10
30
01
3A
2
15
30
38
50
50
50
---
---
48
55
50
35
02 1/
3A
2
15
30
38
50
50
50
---
---
48
55
50
35
03
3A
1
15
29
35
45
45
50
---
---
48
55
50
35
04 1/
3A
1
15
29
35
45
45
50
---
---
48
55
50
35
05
5A
2
6
19
28
42
45
50
---
---
30
50
30
30
06 1/
5A
2
6
19
28
42
45
50
---
---
30
50
30
30
07
5A
1
8
19
25
38
40
45
---
---
30
50
30
30
08 1/
5A
1
8
19
25
38
40
45
---
---
30
50
30
30
09
10 A 2/
2
6
19
28
42
45
50
---
---
30
50
30
30
10 1/
10 A 2/
2
6
19
28
42
45
50
---
---
30
50
30
30
11
10 A 2/
1
8
19
25
38
40
45
---
---
30
50
30
30
12 1/
10 A 2/
1
8
19
25
38
40
45
---
---
30
50
30
30
1/ Equipped with metric insert.
2/ Limited to 6 amperes at 250 V ac by IEC connector.
FIGURE 1. Electrical schematic.
