MIL-PRF-28861/2C
Inches
mm
Inches
mm
3.68
.003
0.08
.145
A
4.75
.005
0.13
.187
dimension
Dash
5.08
.007
0.18
.200
(±.010)
number
6.35
.010
0.25
.250
001
7.92
.015
0.38
.312
.187
through
10.03
.022
0.56
.395
012
10.36
.045
1.14
.408
013
10.41
.070
1.78
.410
.312
through
20.14
.093
2.36
.793
024
.115
2.92
NOTES:
1. Dimension are in inches.
2. Metric equivalents are given for general information only.
3. Circuit diagrams are for information only.
4. All filters shall be supplied with mounting hardware (hex nut and lockwasher). Mounting hardware shall be
furnished with the same finish as the filter case.
5. Terminal identification (nonsymmetrical filters): The case shall be marked at the threaded end of the filter
with the symbol "C" or the symbol "L" as follows, or the circuit diagram shall be marked on the case.
Circuit
Symbol
L1
C
L
L2
Optional slot may be supplied, .050 ±.010 inches (1.27 ± 0.25 mm) x .070 ± .010 inches (1.78 ± 0.25 mm).
6.
7.
Imperfect thread or undercut optional .050 inch (1.27 mm) maximum.
8.
One imperfect thread allowed .035 inch (0.89 mm) maximum.
Recommended mounting torque: 44 inch-ounce ± 4 inch-ounces.
9.
FIGURE 1. Case and hardware dimensions and circuit diagrams - Continued.
