MIL-PRF-15733/57D
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Case: Metal.
*
Case and mounting hardware finish: In accordance with MIL-PRF-15733. Pure tin finish is prohibited as specified in
Terminals: Solder lug.
Operating temperature range: -55C to +125C.
Rated voltage: 150 V dc at 125C; 125 V ac, 400 hertz at 125C.
Rated current: See table I.
Insertion loss: In accordance with MIL-PRF-15733 and table I.
TABLE I. Electrical characteristics.
Dash
Maximum
Minimum insertion loss (dB) in accordance with MIL-STD-220 1/
At +25C
At -55C and +125C
number
rated
current
100
150
300
1
10
100
1
100 150 300
1
10
100
1
(ampere)
kHz
kHz
kHz MHz MHz MHz GHz
kHz kHz kHz MHz MHz MHz
GHz
0001
0.5
18
24
28
58
60
60
60
16
22
26
56
60
60
60
1/ Insertion loss measurements shall be made under full load over the frequency range of 100 kHz to 10 MHz.
Insertion loss measurements above this frequency range shall be under no-load.
Seal: In accordance with MIL-PRF-15733.
Temperature rise: In accordance with MIL-PRF-15733; 25C, maximum.
Dielectric withstanding voltage: In accordance with MIL-PRF-15733. The following exceptions shall apply:
Test temperature: 25C.
Test voltage: 2.0 times the rated dc voltage applied between each terminal and ground, for a period
of 1 to 5 seconds.
condition C (70,000 ft). The following details apply:
Dielectric withstanding voltage: 125 percent of the rated dc voltage for 60 seconds.
Insulation resistance: In accordance with MIL-PRF-15733. The following details and exceptions shall apply:
Test temperature: 25C.
Test potential: Rated dc voltage.
Maximum charging current: 150 milliamperes for 2 minutes.
Insulation resistance: Shall be not less than 1,000 megohms.
3
