MIL-PRF-15733/56D
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Case: Metal.
Case and mounting hardware finish: In accordance with MIL-PRF-15733. Pure tin finish is prohibited.
Weight: 8.5 grams, maximum (0001 and 0002).
9 grams, maximum (0003).
Terminals: Solderable.
Seal: Glass to metal.
Operating temperature range: -55°C to +125°C.
Rated voltage: 50 V dc.
Rated current: See table I.
Insertion loss: In accordance with MIL-PRF-15733 and table I.
Seal: In accordance with MIL-PRF-15733.
Temperature rise: In accordance with MIL-PRF-15733; 25°C, maximum.
Dielectric withstanding voltage: In accordance with MIL-PRF-15733. The following exceptions shall apply:
Test temperature: 25°C.
Test voltage: 100 V dc applied between each terminal and ground, for a period of 1 to 5 seconds.
Insulation resistance: In accordance with MIL-PRF-15733. The following details shall apply:
Test temperature: 25°C.
Insulation resistance: Shall be not less than 1,000 megohms.
Voltage drop: In accordance with MIL-PRF-15733 and table I.
TABLE I. Electrical characterisitcs.
Maximum
Maximum
Dash
Circuit
DC
Minimum full-load insertion loss (dB)
number
configuration
resistance
in accordance with MIL-STD-220
voltage
rated
at 25°C
(ohms)
drop
current
(volts)
(amperes)
Above 1 MHz
0001
.1
2.0
.2
80
2L1
0002
1.5
.3
.45
80
2L1
0003
5
.1
.5
55 dB at 50 kHz, 90 dB from
2L2
120 kHz to 1 GHz
3
