MIL-PRF-15733/56D
Dimensions
A
B
C
D
E
F
G
H
Dash
number
Max
Max
Max
Min
Max
Max
Min
Max
Min
Max
Slot or hole
±.010
0001
1.050
.410
.352
.177
.197
.190
.085
.120
.196
.206
.050 x .070
(26.67)
(10.41)
(8.94)
(4.50)
(5.00)
(4.83)
(2.16)
(3.05)
(4.98)
(5.23)
or .050 dia
0002
1.050
.410
.352
.177
.197
.190
.085
.120
.196
.206
.050 x .070
(26.67)
(10.41)
(8.94)
(4.50)
(5.00)
(4.83)
(2.16)
(3.05)
(4.98)
(5.23)
or .050 dia
0003
1.09
.416
.352
.180
.200
.190
.085
.120
.196
.206
.050 x .070
(27.7)
(10.57)
(8.94)
(4.57)
(5.08)
(4.83)
(2.16)
(3.05)
(4.98)
(5.23)
or .050 dia
REF
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Circuit diagram is for information only.
4. All filters shall be supplied with mounting hardware.
5. Use of style FL61 with or without shoulder is optional.
6. Terminal identification (nonsymmetrical filters): The case shall be marked at the threaded end of the filter, with the
symbol "C" or "L" as follows:
Circuit
Symbol
2L1
C
2L2
L
FIGURE 1. Case and circuit configuration. (continued)
