MIL-PRF-15733/46C
TABLE III. Insertion loss versus frequency.
Minimum no-load insertion loss (dB) in accordance with MIL-STD-220, at +25°C.
Dash
number
50 MHz
100 MHz
200 MHz
500 MHz
1-10 GHz
0001
50
65
70
70
70
Part or Identifying Number (PIN): M15733/46-0001
Marking: Filters shall be marked, as a minimum, with an abbreviated PIN as shown on figure 2. Full marking, in
accordance with MIL-PRF-15733, shall be marked on the unit package.
M1
57
33
46
00
01
FIGURE 2. Example of marking for the abbreviated PIN on the hex flats - expanded view.
Application note: These nonhermetically sealed filters may be susceptible to moisture intrusion when subjected to
repeated thermal cycling. If these items are to be utilized in applications enduring harsh environments, the user
should consider placing them within hermetic enclosures.
Changes from previous issue. Marginal notations are not used in this revision to identify changes with respect to
the previous issue due to the extensiveness of the changes.
Custodians:
Preparing activity:
Navy - EC
DLA - CC
Air Force 11
DLA CC
(Project 5915-0422)
Review activities:
Navy - AS, MC, OS
Air Force - 19, 99
4
