MIL-PRF-15733/31F
Mounting Hardware
E
C
D
A
B
±.005
±.006
±.003
±.005
THD
(.13)
(.13)
(.15)
(.08)
.3125 - 24
.437
.125
.430
.022
UNF-2B
(11.10)
(3.18)
(10.92)
(.56)
.4375 - 20
.625
.125
.780
.035
UNF-2B
(15.88)
(3.18)
(19.81)
(.89)
.6250 - 24
.875
.156
.875
.022
UNEF-2B
(22.22)
(3.96)
(22.22)
(.56)
.7500 - 20
1.062
.156
1.062
.022
UNEF-2B
(26.98)
(3.96)
(26.98)
(.56)
1.000 - 14
1.500
.187
1.614
.062
UNS-2B
(38.10)
(4.75)
(41.00)
(1.57)
1.125 - 18
1.625
.187
1.812
.062
UNEF-2B
(41.28)
(4.75)
(46.02)
(1.57)
FIGURE 1. Case dimensions and circuit diagrams - Continued.
