TABLE I. Filter dimensions.
Dash
number
A
B
C
D
E
F
G
H
Min
Max
Min
Max
Min
Max
Max
Max
Min
Max
Mounting
Terminal
thread
thread
0001
3.19
3.31
1.23
1.26
.480
.520
.69
.69
.520
.540
.625-24
.164-32
(81.03)
(84.07)
(31.24)
(32.00)
(12.19)
(13.21)
(17.53)
(17.53)
(13.21)
(13.72)
UNC-2A
UNC-2A
0002
4.94
5.06
1.73
1.76
.480
.520
.69
.69
.646
.666
.750-20
.164-32
(125.48)
(128.52)
(43.94)
(44.60)
(12.19)
(13.21)
(17.53)
(17.53)
(16.41)
(16.92)
UNC-2A
UNC-2A
TABLE II. Insertion -loss (dB) versus frequency (MHz).
Minimum insertion loss full load in accordance with MIL-STD-220 at +25°C.
Dash
Rated
number
voltage
0.15 MHz
0.3 MHz
0.6 MHz
1 MHz
10 MHz
20 MHz
40 MHz
100 MHz
0001
100 V dc
40
58
74
80
80
80
80
80
0002
400 V dc
(115 Vac
40
58
74
80
80
80
80
80
0-400 Hz)
