MIL-F-15733/30F
TABLE I. Electrical characteristics.
Dash
Rated
Minimum insertion loss (dB) in accordance with
MIL-STD-220 at 25°C 1/
number
current
(amperes)
150
300
600
1
10
100
1
kHz
kHz
kHz
MHz
MHz
MHz
GHz
0001
2
50
60
60
60
60
60
60
0002
2
50
60
60
60
60
60
60
0003
.5
40
50
60
60
60
60
60
0004
1
40
50
60
60
60
60
60
0005
3
40
50
60
60
60
60
60
0006
5
40
50
60
60
60
60
60
0007
10
40
50
60
60
60
60
60
0008
20
37
46
54
58
60
60
60
0009
30
37
46
54
58
60
60
60
0010
50
37
46
54
58
60
60
60
1/ No-load insertion loss measurements shall be performed at 100 MHz and 1 GHz. Full-load insertion
loss measurements shall be performed from 150 KHz to 10 MHz.
REQUIREMENTS:
Configurations and dimensions: See figure 1.
Case: Metal.
Case and mounting hardware finish: In accordance with MIL-PRF-15733. Pure tin finish is prohibited.
Rated voltage: 100 V dc, 30 V ac.
Rated current: See table I.
Insertion loss: In accordance with MIL-PRF-15733 and table I.
Operating temperature range: -55°C to +125°C.
Seal: In accordance with MIL-PRF-15733.
Temperature rise: In accordance with MIL-PRF-15733 and the following:
25°C maximum for parts rated up to and including 10 amperes.
35°C maximum for parts rated above 10 amperes.
Insulation resistance: In accordance with MIL-PRF-15733. Insulation resistance shall be 1,000 megohms
minimum when measured at +25°C between both terminals connected together and the case.
Terminal strength: In accordance with MIL-PRF-15733 and method 211 of MIL-STD-202. The following details
shall apply:
Style 1 - Test condition A (applied force: 9 pounds) and Test condition B (5 bends).
Style 2 - Test condition E, torque shall be as specified in MIL-PRF-15733.
3
