Physical characteristics.
Style
Dash
Dimensions
Terminal
Terminal
Mounting
number
thread
thread length
thread
A
B
C
D
E
F
G
Min
Max
Max
Max
Max
Min
Max
Max
Min
Max
1
0001
2.56
2.68
1.25
.370
.50
.44
.56
.50
N/A
N/A
N/A
.438-20UNF-2A
(65.0)
(68.1)
(31.8)
(9.40)
(12.7)
(11.2)
(14.2)
(12.7)
2
0002
2.56
2.68
1.25
.370
.69
.44
.56
.87
.164-32
.312
.375
.438-20UNF-2A
(65.0)
(68.1)
(31.8)
(9.40)
(17.5)
(11.2)
(14.2)
(22.1)
UNC-2A
1
0003
2.19
2.31
1.02
.380
.25
.42
.46
.25
N/A
N/A
N/A
.438-20UNF-2A
(55.6)
(58.7)
(25.9)
(9.65)
(6.4)
(10.7)
(11.7)
(6.4)
1
0004
2.81
2.93
1.02
.380
.25
.42
.46
.25
N/A
N/A
N/A
.438-20UNF-2A
(71.4)
(74.4)
(25.9)
(9.65)
(6.4)
(10.7)
(11.7)
(6.4)
1
0005
4.13
4.25
1.27
.380
.25
.42
.46
.25
N/A
N/A
N/A
.438-20UNF-2A
(104.9)
(108.0)
(32.3)
(9.65)
(6.4)
(10.7)
(11.7)
(6.4)
2
0006
3.82
3.94
1.52
.666
.69
.48
.52
.69
.164-32
.312
.375
.750-20UNEF-2A
(97.0)
(100.1)
(38.6)
(16.92)
(17.5)
(12.2)
(13.2)
(17.5)
UNC-2A
2
0007
3.82
3.94
1.77
.666
.69
.48
.52
.69
.164-32
.312
.375
.750-20UNEF-2A
(97.0)
(100.1)
(45.0)
(16.92)
(17.5)
(12.2)
(13.2)
(17.5)
UNC-2A
2
0008
3.94
4.06
1.52
.666
.69
.48
.52
.69
.164-32
.312
.375
.750-20UNEF-2A
(100.1)
(103.1)
(38.6)
(16.92)
(17.5)
(12.2)
(13.2)
(17.5)
UNC-2A
2
0009
4.69
4.81
2.27
1.075
.81
.54
.58
.81
.190-32
.312
.375
1.125-18UNEF-2A
(119.1)
(122.2)
(57.7)
(27.30)
(20.6)
(13.7)
(14.7)
(20.6)
UNF-2A
2
0010
5.44
5.56
2.27
1.075
.88
.54
.58
.88
.250-20
.44
.50
1.125-18UNEF-2A
(138.2)
(141.2)
(57.7)
(27.30)
(22.4)
(13.7)
(14.7)
(22.4)
UNC-2A
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are in parentheses.
3. Metric equivalents are given for general information only.
4. Circuit diagram is for information only.
5. Mounting hardware shall be supplied with filter.
FIGURE 1. Case and circuit configuration (continued).
