A-A-55166B
Case style B
PIN
Case
A
B
C
D
E
AA55166-
style
(max)
(max)
(max)
(max)
.015/ .38
Inch
mm
Inch
mm
Inch
mm
Inch
mm
Inch
mm
01
2.72
69.1
1.82
46.2
1.16
29.5
2.125
53.98
2.53
64.3
A
02
3.46
87.9
2.07
52.6
1 16
29.5
2.375
60.33
2.81
71.4
A
03
3.46
87.9
2.07
52.6
1.16
29.5
2.375
60.33
2.81
71.4
A
04
3.46
87.9
2.56
65.0
1.53
38.9
2.938
74.63
3.35
85.1
A
05
5.34
135.6
3.38
85.9
1.53
38.9
3.750
95.25
4.20
106.7
B
06
5.34
135.6
3.38
85.9
1.53
38.9
3.750
95.25
4.20
106.7
B
NOTES:
1.
Dimensions are in inches.
2.
Metric equivalents are given for general information only.
3.
Terminals: (Five) No. 8-32.
4.
Mounting holes for -1 through -04: (Two) .188 inch (4.78 mm) diameter.
Mounting slots for -05 and -06: (Four) .250 inch (6.35 mm) x .156 inch (3.96 mm).
5. Metric equivalents are in parentheses.
FIGURE 2. Case configuration and dimensions - Continued.
