A-A-55166B
TABLE I. Current rating and insertion loss.
Minimum insertion loss (dB)
Line-to-ground in 50 -ohm circuit
PIN
Current rating
Electrical
AA55166-
schematic
Frequency (MHz)
.15
.5
1
5
10
30
01
10 A
A
7
20
25
40
45
48
02
10 A
B
6
19
28
42
45
50
03
20 A
A
7
20
25
40
45
48
04
20 A
B
6
19
28
42
45
50
05
30 A
A
7
20
25
40
45
48
06
30 A
B
6
19
28
42
45
50
Schematic A
Schematic B
FIGURE 1. Electrical schematics.
Case style A
FIGURE 2. Case configuration and dimensions.
2
