MIL-F-15733/2L
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Case: Metal.
Case and mounting hardware finish: In accordance with MIL-PRF-15733. Pure tin finish is prohibited as specified
*
in MIL-PRF-15733.
Terminals:
Style 1: Solderable.
Style 2: Threaded stud.
*
Recommended terminal torque:
Thread
Torque (in-lb)
.190-32
16 to 18
UNF-2A
.250-28
35 to 40
UNF-2A
*
Recommended mounting torque:
Thread
Torque (in-lb)
Thread
Torque (in-lb)
.500-28
85 to 95
.750-20
120 to 140
UNEF-2A
UNEF-2A
.625-24
100 to 115
1.125-18
150 to 175
UNEF-2A
UNEF-2A
Weight: See figure 1.
Operating temperature range: -55°C to +85°C.
Rated (power) frequency: 0 to 400 Hz.
Rated voltage: See table I.
Rated current: See table I.
Insertion loss: In accordance with MIL-PRF-15733 and the following:
(at +25°C): See table I.
(at -55°C and +85°C): Insertion loss shall be as specified in table I except that a degradation of 2 dB from the
value specified in table I shall be allowed up to 10 MHz.
Seal: In accordance with MIL-PRF-15733.
Temperature rise: +25°C maximum for parts rated up to and including 10 amperes.
+35°C maximum for parts rated above 10 amperes.
Dielectric withstanding voltage: In accordance with MIL-PRF-15733 except the duration of application of voltage
shall be 1 to 5 seconds.
