A-A-55170B
Case style B
Case
A
B
C
D
E
±.015/±.38
style
(max)
(max)
(max)
(max)
PIN
AA55170-
Inch
mm
Inch
mm
Inch
mm
Inch
mm
Inch
mm
01
3.96
100.6
2.07
52.6
1.53
38.9
2.938
74.63
3.35
85.1
A
02
5.34
135.6
3.37
85.6
1 53
38.9
3.750
95.25
4.20
106.7
B
NOTES:
1.
Dimensions are in inches.
2.
Metric equivalents are given for general information only.
3.
Terminals: No. 8-32 (five).
4.
Mounting holes: (Two) .188 inch (4.78 mm) diameter.
5.
Mounting slots: (Four) .250 inch (6.35 mm) x .156 inch (3.96 mm).
6.
Metric equivalents are in parentheses.
FIGURE 2. Case configuration and dimensions - Continued.
3
