A-A-55167B
Case style B
Case
B
C
D
E
A
style
(max)
(max)
(max)
(max)
PIN
.015/ .38
AA55167-
Inch
mm
Inch
mm
Inch
mm
Inch
mm
Inch
mm
01
3.35
85.1
1.81
46.0
1.16
29.5
2.375
60.33
2.78
70.6
A
02
3.35
85.1
1.81
46.0
1 16
29.5
2.375
60.33
2.78
70.6
A
03
3.85
97.8
2.07
52.6
1.16
29.5
2.938
74.63
3.35
85.1
A
04
3.85
97.8
2.07
52.6
1.16
29.5
2.938
74.63
3.35
85.1
A
05
3.85
97.8
2.07
52.6
1.53
38.9
2.938
74.63
3.35
85.1
A
06
5.23
132.8
3.37
85.6
1.53
38.9
3.750
95.25
4.20
106.7
B
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Fastons: (Five) .250 inch (6.35 mm).
Holes: .07 inch (1.8 mm) diameter.
4. Mounting holes: (Two) .188 inch (4.78 mm) diameter.
5. Mounting slots: (Four) .250 inch (6.35 mm) x .156 inch (3.96 mm).
6. Metric equivalents are in parentheses.
FIGURE 2. Case configuration and dimensions - Continued.
