[INCH-POUND]
A-A-55090A
September 17, 2001
SUPERSEDING
A-A-55090
November 22, 1991
COMMERCIAL ITEM DESCRIPTION
FILTER, RADIO FREQUENCY INTERFERENCE
The General Services Administration has authorized the use
of this commercial item description (CID) for all federal agencies.
1. SCOPE. This CID covers the general requirements for radio frequency interference (RFI) suppression power line
filters. These filters consist of capacitors and inductors used in combination with each other and may be provided
with resistors. This series of RFI filters incorporate the special IEC (International Electrotechnical Commission)
power line connector. Filters covered by this CID are intended for commercial/industrial applications and should not
be used in military systems needing stringent environmental and electrical requirements.
2. CLASSIFICATION. This CID uses a classification system which is included in the Part Identification Number
(PIN) as shown in the following example (see 7.1).
AA55090
-
01
CID number
Dash number
3. SALIENT CHARACTERISTICS.
3.1 Interface and physical dimensions. Filters supplied to this CID shall be as specified herein (see figure 1).
3.2. Voltage rating. The voltage rating shall be 120/250 V ac.
3.3 Operating frequency. The operating frequency shall be 50/60 Hz.
3.4 Current rating. The current rating shall be as specified in table I.
3.5 Maximum leakage current, line-to-ground. The maximum leakage current, line-to-ground, shall be 0.25 mA at
120 V ac, 60 Hz; 0.50 mA at 250 V ac, 50 Hz.
TABLE I. Current rating and insertion loss.
Minimum insertion loss (dB)
Line-to-ground in 50 ohm circuit
PIN
Current rating
AA55090-
Frequency (MHz)
.15
.5
1
5
10
30
01
1A
22
35
40
46
50
49
02
3A
15
25
30
45
50
54
03
6A
9
20
25
41
45
50
Beneficial comments recommendations, additions, deletions, clarifications, etc., and any data which may improve
this document should be addressed to: Defense Supply Center, Columbus, ATTN: DSCC-VAT, Post Office Box
3990, Columbus, OH 43213-1199, or telephone (614) 692-0562, or facsimile (FAX) (614) 693-1644.
AMSC N/A
FSC 5915
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
